Xct100L7-1 High Quality 100 Ton Second Hand Mobile Telescopic Arm Truck Crane

MOQ : 1

Price : US$200,000.00 - 250,000.00

Ton : 6 Ton

Span : 65m,3-50/55M,0-80m,60m,3.5~75 m

Appy To : Building

Delivery : Sea

Model : Tower Crane

Type : Used

Warranty : 1 year

Shipmnet Way : Air Sea

Shipment Way : Air and Sea

Key Word : 5610-6 Second Hand Tower Crane

Condition : Good

Max Lifting Height : 60 meters

Power Source : Electric

Feature : Tower Crane

Payment : TT

Contact Now

Basic Info.

Model NO.

XCT100L7_1

Condition

New/Used

Maximum Lifting Height

>40m

Maximum Lifting Weight

100t

Shaft Number

Crane Jib

Type

Straight Arm

Total Vehicle Mass

49800kg

Max. Rated Lifting Capacity X Working Ra

100000kg*3m

Min. Ground Clearance

326mm

Max. Travel Speed

90km/H

Transport Package

Comply with Export Packaging Requirment

Specification

15600*3000*3870mm

Trademark

JUQIANGDA

Origin

China

HS Code

8705109100

Production Capacity

1000

Product Description

Xct100L7-1 High Quality 100 Ton Second Hand Mobile Telescopic Arm Truck Crane

Description		Unit	Parameter value
Overall length		mm	15600
Overall width		mm	3000
Overall Height		mm	3870
Wheel Base		mm	1920+3500+1420+1505
Track(front/rear)		mm	2449/2315
Front/Rear overhang		mm	2650/2765
Front/Rear extension		mm	1840/0
Total vehicle mass in travel configuration		kg	55000
Axle load	1st and 2nd Axle	kg	10000
	3rd and 4th Axle		13000
	5th Axle		9000
Engine rated power		kw/(r/min)	176/2300	190/2200	316/1900
Engine rated torque		N.m/(r/min)	860/1200-1700	1000/1200-1600	2060/1000-1400
Max. travel speed		km/h	90
Min. turning diameter		m	23
Min. ground clearance		mm	326
Max. grade ability		%	45
Approach angle		°	18
Departure angle		°	13
Braking distance (at 30 km/h, full load )		m	≤10
Oil consumption per 100km		L	70
Noise level at seated position		dB(A)	≤90
Exterior noise level		dB(A)	≤88
